Garland M43-3S Master Gas Ranges
Description
Master Series 34" Heavy-Duty Gas Hot Top Range – 3 Sections, Storage Base
Model reference: Garland M43-3S | 66,000 BTUBuilt for kitchens that never slow down, the Garland Master Series 34" hot-top range delivers rock-solid durability, uniform heat distribution and generous under-counter storage – all in one heavy-duty package that carries the CSA Flame, CSA Star and NSF marks you demand.
Why you’ll love it
- Three 12" cast-iron Even Heat hot tops engineered for continuous surface cooking.
- 22,000 BTU “H” burners under each section (66,000 BTU total) provide fast recovery and precise low-to-high control.
- Independent manual valves let you zone-cook sauces, sautés or holding pans without hot spots.
- Heavy-gauge stainless steel front & sides resist dents, scratches and daily chemicals.
- 7-½" deep stainless front rail doubles as a plating shelf and protects controls from spills.
- Full-width storage base keeps sheet pans, stock pots or hotel pans close at hand – no oven to heat, clean or maintain.
- 6" chrome-steel adjustable legs level the unit on uneven floors.
- Factory-mounted 1-¼" NPT front gas manifold; rear connection kit available.
- Certified CSA Flame, CSA Star & NSF for commercial gas installations.
At-a-glance specifications
| Overall width | 34" (864 mm) |
|---|---|
| Overall depth | 38" (965 mm) |
| Work height (with 6" legs) | 36-3/8" (924 mm) |
| Hot-top sections | 3 × 12" cast-iron plates |
| Total input | 66,000 BTU/hr (19.34 kW) |
| Gas type | Natural or Propane (specify when ordering) |
| Manifold pressure | 4.5" WC Nat. | 10" WC LP |
| Gas connection | 1-¼" NPT front (rear optional) |
| Storage cavity (W × D × H) | 26" × 30-½" × 20-½" (665 × 773 × 519 mm) |
| Shipping weight | Approx. 370 lb (163 kg) |
| Certifications | CSA Flame, CSA Star, NSF |
Popular factory options
- 10", 17" or 33" stainless steel backguard or single / double high shelf.
- Rear gas connection (¾", 1" or 1-¼" NPT).
- Gas regulator or quick-disconnect flex hose with restraining device.
- Set of four non-marking swivel casters with front brakes.
- Stainless steel common front rail for battery line-ups (up to 102" wide).
- End caps and side covers for flush battery installations.
Performance data based on installations up to 2,000 ft (610 m) elevation. For higher altitudes, please specify when ordering so proper orifices can be supplied.
