Description
Garland Master Series 34" Heavy-Duty Gas Range
4 × 24,000 BTU Starfire® Open Burners • 12" Even-Heat Hot Top • Storage BaseBuilt for high-volume, high-heat kitchens, the Garland Master Series combines legendary durability with the cooking versatility chefs demand every day. Four lightning-fast Starfire® open burners sit beside a 12 inch extra-heavy cast-iron hot top, all above a roomy stainless-steel storage base—perfect when you need more cookware space instead of an oven.
Why You’ll Love It
- 118,000 BTU total input for rapid searing, boiling and gentle holding.
- Starfire® open burners (32 MJ each) with removable two-piece cast-iron grates for fast cleanup.
- 12" Even-Heat hot top (22,000 BTU) delivers consistent surface temperatures—ideal for stockpots & sauce pans.
- Stainless-steel front, sides & 7 ½" full-width rail stand up to the toughest commercial kitchens.
- One-piece stainless drip tray and burner box for quick crumb & spill removal.
- 6" adjustable chrome-steel legs for easy leveling on uneven floors.
- Spacious cabinet base keeps sheet pans, stockpots and utensils within arm’s reach.
- Individual manual gas valves on every burner for exact flame control.
- Front 1 ¼" NPT gas connection (rear connection available to order).
- Certified to CSA Flame, CSA Star & NSF standards.
Performance & Capacities
Open Burners | 4 × 24,000 BTU (7 kW) Starfire® |
---|---|
Hot Top Section | 1 × 12" cast-iron, 22,000 BTU (6.45 kW) |
Total Gas Input | 118,000 BTU / 34.6 kW |
Manifold Operating Pressure | Natural Gas 6" WC • LP Gas 10" WC |
Gas Connection | 1 ¼" NPT (front, factory-standard) |
Dimensions
Width | 34" (864 mm) |
---|---|
Depth (incl. rail) | 38" (965 mm) |
Work-surface Height | 36 ⅜" (924 mm) with NSF legs |
Storage Base Interior (W×D×H) | 26" × 30 ½" × 20 ½" (665 × 773 × 519 mm) |
Approx. Shipping Weight | 370 lb (168 kg) |
Certifications
- CSA Flame
- CSA Star
- NSF
A backguard is required on all Master Series units. Casters must be installed with an approved restraining device where local codes require.
