Garland CG-72R Master Gas Griddles
Garland CG-72R Master Gas Griddles is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Garland CG-72R Master Gas Griddles
Description
Garland Master CG-72R EnerLogic™ 72" Gas Countertop Griddle
Rear-drain, electronic-control production griddle – 180,000 BTUReady for the breakfast rush, the lunch crunch and everything after, the 6-ft Garland Master CG-72R pairs rugged construction with precision electronic thermostats. EnerLogic™ technology minimizes idle energy while a full-inch polished steel plate delivers uniform heat and unbeatable sear marks shift after shift.
Why this griddle means business
- Massive 72" × 24" (12 sq ft) cooking surface handles steaks, eggs & veggies side-by-side
- EnerLogic™ smart modulation reduces standby gas consumption without sacrificing recovery
- Six independently controlled U-shaped burners, 30,000 BTU each – 180,000 BTU total
- Electronic thermostats (150 °F–450 °F) with individual on/off switches & indicator lights
- Rear grease trough & twin 1.6 gal (6 L) stainless steel drawers keep the front rail clear
- All-stainless exterior, 8" back-splash & side splashes for quick, sanitary wipe-downs
- Full-width front rail doubles as plating shelf and shields the valve panel
- 6" adjustable stainless legs – perfect for countertop or refrigerated base mounting
- CSA & NSF listed for gas safety and food-service sanitation
Specifications
| Model | Master CG-72R |
|---|---|
| Cooking surface | 72" W × 24" D (1829 mm × 610 mm) |
| Plate thickness | 1" (25 mm) polished steel |
| Burners / Zones | 6 × 30,000 BTU U-shaped (one every 12") |
| Total input | 180,000 BTU/hr (52.7 kW) |
| Temperature range | 150 °F–450 °F (65 °C–232 °C) |
| Controls | Electronic thermostats & electronic ignition |
| Gas connection | 1" rear manifold with factory regulator |
| Manifold pressure | Natural 3.5" W.C. / LP 10" W.C. |
| Electrical | 120 V, 60 Hz, 1 Φ, 1 A (6' cord); 208-240 V option |
| Overall size (w/ legs) | 72" W × 38.75" D × 15.75" H (1829 × 984 × 400 mm) |
| Shipping weight | ≈ 995 lb (451 kg) |
| Certifications | CSA, NSF |
Options & accessories
- 208-240 V wiring (no charge)
- Stainless steel open stand with shelf (legs or casters)
- 10-½" sloped grease drawers (stand-mount units only)
- Protective control shield
- ¾" × 36" quick-disconnect gas hose with restraining device
- 4" low-profile legs & 8.9 L high-capacity grease drawers for refrigerated bases
Looking for a custom gas hookup or field-installed options? Contact our team for tailored solutions.
