Delfield N8731-D Steam Tables & Food Wells
Description
Delfield N8731-D Drop-In Dual Hot Food Well
2 × 12" × 20" individually controlled wells – wet or dry operationExpand your serving line without sacrificing counter space. The N8731-D delivers precise, independent temperature control for two full-size pans, keeping entrées, soups and sides at safe, appetizing temperatures in either wet or dry mode. A factory-installed press-fit gasket lets you drop it in, hook it up and start serving.
Why you’ll love it
- Two separate 6.25" deep stainless steel wells – each holds one 12" × 20" hotel pan or fractional equivalents
- Individual infinite-switch controls on a remote panel (4 ft flexible conduit supplied)
- 1000 W heating element per well (2,000 W total) for rapid heat-up and steady holding
- Wet or dry operation; recessed wells help capture condensation when using water
- ½" NPT drains in each well manifolded to a single gate valve for fast, mess-free draining
- 18-gauge stainless steel top with non-marring press-fit gasket for a clean, flush installation
- Galvanized exterior body plus 1" fiberglass side insulation and 2" bottom blanket to maximize efficiency
- Hard-wired 115 V connection—no cord clutter in the cabinet
- cULus & NSF listed for electrical safety and foodservice sanitation
Technical specifications
| Model | N8731-D |
|---|---|
| Pan capacity | (2) full-size 12" × 20" pans |
| Overall dimensions* | 31.75" L × 26" W × 9.5" H (806 × 660 × 241 mm) |
| Counter cut-out | 30.75" L × 25" W (781 × 635 mm) |
| Well depth | 6.25" (159 mm) |
| Electrical | 115 V / 60 Hz / 1 Φ – 16.6 A – 2,000 W (field hard-wired) |
| Drain connection | (2) ½" NPT manifold to single ½" gate valve (left side) |
| Shipping weight | 99 lb (45 kg) |
| Certifications | cUL, UL, NSF |
*Dimensions include 0.65" perimeter overhang.
Simple installation
- Press-fit perimeter gasket ships pre-installed—no adhesive or caulk required
- 4′ control-panel lead lets you position controls where they’re most convenient
- All drains and wiring exit the left end for straightforward utility hookups
Popular factory options
- Adapter bars or plates for fractional pans
- Single- or double-service flip-up sneeze guards
- Telescoping hinged covers
- 220 V / 50 Hz electrical configuration
- Omit drains & manifold (dry-only applications)
Backed by Delfield’s standard warranty: 1 year parts & 90 days labor.
