Delfield N8731-D Drop-In Dual Hot Food Well
2 × 12" × 20" individually controlled wells – wet or dry operationExpand your serving line without sacrificing counter space. The N8731-D delivers precise, independent temperature control for two full-size pans, keeping entrées, soups and sides at safe, appetizing temperatures in either wet or dry mode. A factory-installed press-fit gasket lets you drop it in, hook it up and start serving.
Why you’ll love it
- Two separate 6.25" deep stainless steel wells – each holds one 12" × 20" hotel pan or fractional equivalents
- Individual infinite-switch controls on a remote panel (4 ft flexible conduit supplied)
- 1000 W heating element per well (2,000 W total) for rapid heat-up and steady holding
- Wet or dry operation; recessed wells help capture condensation when using water
- ½" NPT drains in each well manifolded to a single gate valve for fast, mess-free draining
- 18-gauge stainless steel top with non-marring press-fit gasket for a clean, flush installation
- Galvanized exterior body plus 1" fiberglass side insulation and 2" bottom blanket to maximize efficiency
- Hard-wired 115 V connection—no cord clutter in the cabinet
- cULus & NSF listed for electrical safety and foodservice sanitation
Technical specifications
| Model | N8731-D |
|---|---|
| Pan capacity | (2) full-size 12" × 20" pans |
| Overall dimensions* | 31.75" L × 26" W × 9.5" H (806 × 660 × 241 mm) |
| Counter cut-out | 30.75" L × 25" W (781 × 635 mm) |
| Well depth | 6.25" (159 mm) |
| Electrical | 115 V / 60 Hz / 1 Φ – 16.6 A – 2,000 W (field hard-wired) |
| Drain connection | (2) ½" NPT manifold to single ½" gate valve (left side) |
| Shipping weight | 99 lb (45 kg) |
| Certifications | cUL, UL, NSF |
*Dimensions include 0.65" perimeter overhang.
Simple installation
- Press-fit perimeter gasket ships pre-installed—no adhesive or caulk required
- 4′ control-panel lead lets you position controls where they’re most convenient
- All drains and wiring exit the left end for straightforward utility hookups
Popular factory options
- Adapter bars or plates for fractional pans
- Single- or double-service flip-up sneeze guards
- Telescoping hinged covers
- 220 V / 50 Hz electrical configuration
- Omit drains & manifold (dry-only applications)
Installation note: Unit must be hard-wired and requires at least 3" clearance from combustible materials.
Backed by Delfield’s standard warranty: 1 year parts & 90 days labor.
$2,746.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Delfield N8731-D electric 2-pan drop-in hot food well — stainless steel, wet/dry with drain, individual controls, NSF/cUL listed, durable for buffet use.
Manufacturer
Delfield
Certifications
NSF, UL
Height
9.5in
Width
31.75in
Depth
26.0in
Shipping Weight
99.0lbs
Controls
infinite controls
Style
individual pans
Wet or Dry operation
wet or dry
Construction
stainless steel top, corrosion resistant steel exterior
Drain
with drain
Insulated or Non-Insulated
insulated
Pan Capacity
(2) full size (12" x 20")
Specifications
Drop-In Hot Food Well Unit, Electric, individual pans, wet/dry type with drain & manifold, 2-pan size for 12" x 20" pans, individual infinite temperature controls, stainless steel top & wells, galvanized outer liner, (30-3/4" x 25" cutout required), cUL, UL, NSF
Contact Us
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
