LiquiTec® 3-Pan Drop-In Refrigerated Cold Food Well – Model 8145-EFP
Flush-mount, self-contained cold pan with high-efficiency eutectic fluid technologyDesigned for high-volume serving counters that demand both performance and presentation, the Delfield LiquiTec® 8145-EFP keeps three full-size 12" × 20" pans of cold product safely between 33-41 °F— even in 86 °F ambient conditions. 100 % liner contact with a sealed eutectic bath delivers faster pull-down, longer hold times and a completely flush pan profile that’s easier to load, clean and serve from.
Why you’ll love it
- Eutectic fluid system wraps all 5 sides of the well for superior, even chilling.
- Three individual 12" × 20" stainless wells sit flush with the countertop for unbeatable merchandising and ergonomics.
- Eco-friendly GreenGenius™ refrigeration with R290 hydrocarbon refrigerant and efficient ¼ hp compressor.
- Electronic temperature control with expansion valve maintains NSF-7 certified food-safe temps.
- One-piece stainless steel top, inner liner and ½" drains with copper manifold speed everyday cleaning.
- Press-fit gasket comes factory-installed—drop it in, plug it in (8 ft cord with NEMA 5-15P) and start chilling.
- High-density, zero-ODP / zero-GWP polyurethane foam insulation locks the cold in and energy costs down.
- Stainless steel louver furnished for field installation to ensure proper airflow to the condensing unit.
- cULus, UL Sanitation & NSF listed with a 1-year parts & labor warranty for worry-free ownership.
Technical specifications
| Pan capacity | 3 × 12" × 20" (4" or 6" deep; pans not included) |
|---|---|
| Cut-out required | 44.25" W × 25.00" D (112 cm × 64 cm) |
| Overall well depth | 6.25" (16 cm) |
| Operating temperature | 33 °F – 41 °F (1 °C – 5 °C) @ 86 °F ambient |
| Refrigeration system | Self-contained, R290, eutectic cold-wall |
| Compressor | ¼ hp | 598 BTU load |
| Electrical | 115 V / 60 Hz / 1 Ph, 3.7 A, NEMA 5-15P, 8 ft cord |
| Drain | ½" stainless drains with copper manifold |
| Construction | Stainless steel top & inner liner, galvanized outer housing |
| Insulation | High-density CFC-free polyurethane foam |
| Certifications | cULus, UL, NSF, GreenGenius™ |
| Shipping weight | Approx. 235 lb (107 kg) |
| Warranty | 1 year parts & labor |
Installation note: Provide unobstructed airflow for the condensing unit and mount the included stainless louver in the counter face per the installation manual. Failure to do so will impair performance and void warranty coverage.
Need additional sneeze guards, adapter bars or remote refrigeration? Ask us about factory options and custom configurations built to fit your concept.
$7,262.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Delfield 8145-EFP LiquiTec refrigerated 3-pan drop-in unit: stainless, insulated pans, self-contained R290 cooling, NSF/UL listed, efficient counter-fit.
Manufacturer
Delfield
Brand name
LiquiTec
Certifications
NSF, UL
Height
24.24in
Width
45.32in
Depth
26.0in
Shipping Weight
235.0lbs
Finish
stainless steel top & inner liner, galvanized outer liner
Style
self-contained refrigeration
Layout
deep
Width (side - side)
43 - 48 inches
Insulation
insulated
Pan Size
full-size (12" x 20")
Pan Qty
3-pan
Specifications
LiquiTec® Drop-In Cool Food Unit, 3-pan size, 4" or 6" deep pans flush with counter top, insulated pan, stainless steel inner liner & top, galvanized outer liner, self-contained Eutectic fluid refrigerated system, R290 Hydrocarbon refrigerant, 1/4 hp, (44-1/4" x 25" cutout required), cUL, UL, NSF
Contact Us
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
