Comstock-Castle 3872TG Diner Series Gas Griddles
$16,489.00
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Comstock-Castle 3872TG Diner Series Gas Griddles is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Comstock-Castle 3872TG Diner Series Gas Griddles
$16,489.00
Unit price
/
Unavailable
Description
Comstock-Castle “Diner Series” 72" Countertop Gas Griddle
38 Series | Model 3872T | 180,000 BTU | Thermostatic | NSF ListedServe sunrise-to-late-night menus without missing a beat. The 72" Diner Series griddle delivers massive cooking capacity, rock-solid temperature control and the rugged build quality Comstock-Castle has perfected since 1838.
Key Features & Benefits
- Extra-wide 72" × 30" polished steel cook surface (2,160 in²) handles high-volume orders with ease.
- Full 1" thick plate retains heat for fast recovery and an even sear while its mirror finish reduces food sticking.
- Six independent thermostat zones (150 – 450 °F) let you cook pancakes, burgers and veggies all at once.
- Six 30,000 BTU burners—one under each 12" section—deliver a combined 180,000 BTU of uniform heat.
- 4" stainless splash guard (rear & ends) contains splatter; 3-1/2" bull-nose trough guides grease into the large, front-pull drawer.
- All-stainless exterior, welded frame and insulated side panels stand up to the toughest commercial kitchens.
- 0" clearance to non-combustible surfaces saves precious line space; adjustable 6" legs included.
- Rear-mounted 3/4" NPT gas inlet with factory pressure regulator for quick hook-up.
- NSF listed and proudly made in Quincy, Illinois, USA.
- Backed by Comstock-Castle’s 1-year parts & labor warranty.
Technical Specifications
| Cooking Surface | 72" W × 30" D polished steel (2,160 sq in) |
|---|---|
| Plate Thickness | 1" (25 mm) |
| Heat Zones / Controls | 6 thermostatic zones, 150 – 450 °F (± 20 °F) |
| Burners / Output | 6 × 30,000 BTU (180,000 BTU total) |
| Overall Dimensions | 72" W × 38" D × 17.5" H to plate • add 4" for splash |
| Gas Connection | 3/4" NPT (rear) |
| Recommended Clearances | 0" sides & rear (non-combustible) • 2" sides & 6" rear (combustible) |
| Shipping Weight | ≈ 1,050 lb (477 kg) |
| Certifications | NSF |
| Warranty | 1 year parts & labor |
Perfect For
- 24-hour diners & breakfast spots
- Hotels, resorts & banquet kitchens
- University & corporate cafeterias
- Ghost kitchens & food halls
Installation Notice: This appliance must be installed and pressure-tested by a licensed gas technician.
Adequate ventilation and adherence to local codes are required to maintain safe operation and warranty coverage.
Need a matching equipment stand, chrome plate or grooved sections? Ask our team for available factory options and accessories.
Features & Specs
Features & Specs
Manufacturer
Comstock-Castle
Brand_name
Diner Series
Certifications
NSF
Height
15.75in
Width
72.0in
Depth
38.0in
Shipping Weight
1050.0lbs
Exterior Finish
all stainless steel exterior
Cooking Surface Width (side - side)
67" - 72"
Plate Thickness
3/4"
Griddle Plate Finish
smooth steel
Controls
thermostat / solid state controls
Cooking Surface Depth (front - back)
30" - 36"
Specifications
Diner Series Griddle, countertop, gas, 72" wide x 38" deep frame, 72" wide x 30" deep x 1" thick polished steel griddle plate, (6) thermostat controls, 4" splash guard on back & ends, 3-1/2" wide front grease trough, large removable grease drawer, stainless steel exterior, 180,000 BTU, NSF
