Comstock-Castle Castle Series 10HF Gas Tube Floor Fryer
Slim 11 in. footprint • 24 lb oil capacity • 60,000 BTUBuilt for cramped cook-lines and big appetites, the Castle Series 10HF delivers full-size frying performance in just 11 inches of floor space. A high-efficiency tube-type stainless steel fry tank, rapid-response snap-action thermostat, and deep cold zone work together to turn out crisp, consistent results—hour after hour—in any commercial kitchen.
Why You’ll Love It
- Space-saving 11 in. W chassis—ideal for food trucks, ghost kitchens & tight cook-lines.
- 24 lb (≈ 3.5–4 gal / 13–15 L) oil capacity for fresh, fast batch cooking.
- Stainless steel tube-type heat exchanger with radiant inserts maximizes heat transfer & recovery.
- Snap-action thermostat (200 °F–400 °F) and high-limit safety protect oil life and product quality.
- Automatic standing pilot with 100 % safety shut-off for reliable, worry-free starts.
- Two heavy-duty, nickel-plated wire baskets with hanger rack included.
- All-stainless exterior, welded fry tank & 6 in. adjustable stainless legs for easy cleaning and leveling.
- ¾ in. rear NPT gas connection; 4" WC NG / 10" WC LP manifold pressure.
- NSF-listed & proudly built in the USA by America’s Oldest Stove Company (est. 1838).
Specifications
| Model | Castle Series 10HF (Floor) |
|---|---|
| Oil Capacity | 24 lb ◆ ≈ 3.5–4 gal ◆ 13–15 L |
| BTU Input | 60,000 BTU/hr |
| Overall Dimensions | 11 in. W × 21.75 in. D × 40 in. H |
| Tank Interior (WxLxH to tube) | 10 in. × 15.875 in. × 8 in. |
| Shipping Weight | Approx. 125 lb |
| Gas Connection | ¾ in. NPT (rear) |
| Clearances* | 2 in. sides, 6 in. rear (non-combustible) |
| Certifications | NSF |
*Combustible surfaces require 6 in./6 in. side & rear clearance.
What’s Included
- (2) nickel-plated fryer baskets with cool-touch coated handles
- Stainless steel basket hanger & removable crumb screen
- 1 in. drain valve with pipe extension for fast, safe oil disposal
Popular Accessories (sold separately)
- Single large basket
- Stainless steel tank cover
- Gas quick-disconnect hose kit
- Swivel or rigid casters
Warranty
Backed by Comstock-Castle’s 1-year parts & labor warranty (60 days labor / 120 days parts for mobile & outdoor applications).
Installation Notice: This appliance must be installed & commissioned by a
licensed gas professional. Calibration, leveling, and gas pressure verification are the
responsibility of the end user/operator.
$5,654.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Comstock-Castle 10HF gas floor fryer — 60,000 BTU, 24 lb fat, stainless steel tank/exterior, snap thermostat, NSF-certified for commercial kitchens.
Manufacturer
Comstock-Castle
Brand name
Castle Series
Certifications
NSF
Height
40.0in
Width
11.0in
Depth
21.75in
Shipping Weight
125.0lbs
Fry pot
stainless steel fry pot
Exterior Finish
all stainless steel exterior
Basket Lifts
without basket lifts
Fat Capacity (approximate)
25 lb
Filter
no filter
Controls
thermostatic controls
Type
restaurant
Specifications
Castle Series Fryer, Floor Model, Gas, 11" wide, 24 lb. fat capacity, tube type, snap action thermostat, standing pilot, stainless steel fry tank, stainless steel exterior, 6" stainless steel legs, ¾" rear gas connection, 60,000 BTU, NSF
