American Range | SKU:
ARTG-72-24
American Range ARTG-72-24 Gas Griddles
$8,599.88
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
American Range ARTG-72-24 Gas Griddles is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
American Range ARTG-72-24 Gas Griddles
$8,599.88
Unit price
/
Unavailable
Description
American Range ARTG-72-24 72" Countertop Thermostatic Gas Griddle
1" Polished Steel Plate • 6 Burners • 180,000 BTU • Made in USABuilt for relentless commercial duty, the American Range ARTG-72-24 gives you a vast 72-inch cooking surface with precision zone control. A full-inch thick polished steel plate teams with six independent U-shaped burners to bring fast recovery, even heating and flawless results shift after shift.
Key Features
- Heavy-duty 1" (25 mm) smooth polished steel griddle plate for superior heat retention.
- Six 30,000 BTU U-shaped burners—one every 12"—deliver uniform heat (total 180,000 BTU / 53.0 kW).
- Independent modulating thermostats with standing pilots; temperature range 250 °F – 500 °F (121 °C – 260 °C).
- 3" wrap-around stainless steel splash guard contains splatter.
- Full-length 3" stainless steel grease trough and extra-large removable grease pan speed clean-up.
- Stainless steel front, sides, landing ledge and controls built for long service life.
- 4" adjustable stainless steel legs for quick, level placement on any countertop.
- ETL Listed for gas & sanitation; complies with ANSI/NSF standards.
- Designed & manufactured in California, USA.
Ideal For
- Diners, cafés & breakfast programs
- Burgers, steaks, sandwiches & all-day menus
- High-volume production kitchens & catering commissaries
Specifications
| Model | ARTG-72-24 |
|---|---|
| Cooking surface | 72" W × 24" D (1,829 mm × 610 mm) |
| Overall dimensions | 72" W × 35" D × 17" H (1,829 mm × 889 mm × 432 mm) |
| Plate thickness | 1" (25 mm) polished steel |
| Burners / Output | 6 × 30,000 BTU U-shaped (180,000 BTU total) |
| Control type | Individual thermostats, 250 °F–500 °F |
| Gas connection | 3/4" NPT, Natural or Propane (specify) |
| Shipping weight | Approx. 770 lb (349 kg) |
| Certifications | ETL Gas, ETL Sanitation |
| Warranty | 2-year limited parts & labor |
Installation & Clearance Notes
- For use on non-combustible countertops or curb-mounted with 2" overhang.
- Combustible wall clearances: 12" from sides, 4" from rear.
- Requires adequate ventilation in accordance with NFPA 96.
- Specify gas type and altitude (over 2,000 ft / 610 m) when ordering.
Important: Installation and hookup must be performed by a qualified professional in accordance with local codes. Failure to follow manufacturer guidelines may void warranty.
Need a different width? American Range thermostatic griddles are also available in 24", 36", 48" and 60" models.
Features & Specs
Features & Specs
Manufacturer
American Range
Certifications
ETL, Made in USA
Height
10.5in
Width
72.0in
Depth
30.0in
Shipping Weight
600.0lbs
Plate Thickness
3/4"
Griddle Plate Finish
smooth steel
Exterior Finish
stainless steel front & sides
Controls
thermostat / solid state controls
Cooking Surface Width (side - side)
67" - 72"
Specifications
Griddle, gas, 72" W x 24"D, countertop, 1" thick smooth polished steel griddle plate,(6) "U" shaped burners, modulating thermostatic controls with pilot, 3" splash guard, 4" legs, stainless steel grease trough & grease pan, stainless steel exterior, 53.0kW, 180,000 BTU, ETL, Made in USA
