American Range ARTG-72-24 72" Countertop Thermostatic Gas Griddle
1" Polished Steel Plate • 6 Burners • 180,000 BTU • Made in USABuilt for relentless commercial duty, the American Range ARTG-72-24 gives you a vast 72-inch cooking surface with precision zone control. A full-inch thick polished steel plate teams with six independent U-shaped burners to bring fast recovery, even heating and flawless results shift after shift.
Key Features
- Heavy-duty 1" (25 mm) smooth polished steel griddle plate for superior heat retention.
- Six 30,000 BTU U-shaped burners—one every 12"—deliver uniform heat (total 180,000 BTU / 53.0 kW).
- Independent modulating thermostats with standing pilots; temperature range 250 °F – 500 °F (121 °C – 260 °C).
- 3" wrap-around stainless steel splash guard contains splatter.
- Full-length 3" stainless steel grease trough and extra-large removable grease pan speed clean-up.
- Stainless steel front, sides, landing ledge and controls built for long service life.
- 4" adjustable stainless steel legs for quick, level placement on any countertop.
- ETL Listed for gas & sanitation; complies with ANSI/NSF standards.
- Designed & manufactured in California, USA.
Ideal For
- Diners, cafés & breakfast programs
- Burgers, steaks, sandwiches & all-day menus
- High-volume production kitchens & catering commissaries
Specifications
| Model | ARTG-72-24 |
|---|---|
| Cooking surface | 72" W × 24" D (1,829 mm × 610 mm) |
| Overall dimensions | 72" W × 35" D × 17" H (1,829 mm × 889 mm × 432 mm) |
| Plate thickness | 1" (25 mm) polished steel |
| Burners / Output | 6 × 30,000 BTU U-shaped (180,000 BTU total) |
| Control type | Individual thermostats, 250 °F–500 °F |
| Gas connection | 3/4" NPT, Natural or Propane (specify) |
| Shipping weight | Approx. 770 lb (349 kg) |
| Certifications | ETL Gas, ETL Sanitation |
| Warranty | 2-year limited parts & labor |
Installation & Clearance Notes
- For use on non-combustible countertops or curb-mounted with 2" overhang.
- Combustible wall clearances: 12" from sides, 4" from rear.
- Requires adequate ventilation in accordance with NFPA 96.
- Specify gas type and altitude (over 2,000 ft / 610 m) when ordering.
Important: Installation and hookup must be performed by a qualified professional in accordance with local codes. Failure to follow manufacturer guidelines may void warranty.
Need a different width? American Range thermostatic griddles are also available in 24", 36", 48" and 60" models.
$8,599.88
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
American Range 72" gas griddle: 1" polished steel plate, 6 burners, thermostatic controls, stainless exterior, 180,000 BTU, countertop, U.S.A.
Manufacturer
American Range
Certifications
ETL, Made in USA
Height
10.5in
Width
72.0in
Depth
30.0in
Shipping Weight
600.0lbs
Plate Thickness
3/4"
Griddle Plate Finish
smooth steel
Exterior Finish
stainless steel front & sides
Controls
thermostat / solid state controls
Cooking Surface Width (side - side)
67" - 72"
Specifications
Griddle, gas, 72" W x 24"D, countertop, 1" thick smooth polished steel griddle plate,(6) "U" shaped burners, modulating thermostatic controls with pilot, 3" splash guard, 4" legs, stainless steel grease trough & grease pan, stainless steel exterior, 53.0kW, 180,000 BTU, ETL, Made in USA
