American Range | SKU:
ARTG-60-24
American Range ARTG-60-24 Gas Griddles
$7,082.25
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
American Range ARTG-60-24 Gas Griddles is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
American Range ARTG-60-24 Gas Griddles
$7,082.25
Unit price
/
Unavailable
Description
American Range ARTG-60-24 60" Thermostatic Gas Griddle
150,000 BTU • 1" Polished Steel Plate • Made in USABuilt for demanding food-service operations, the American Range ARTG-60-24 delivers precise, even heat across a massive 60" x 24" cooking surface. Five independent thermostats give you menu-to-menu flexibility while the heavy 1" steel plate locks in heat for rapid recovery.
Key Features
- 1" (25 mm) smooth polished steel griddle plate for superior heat retention and even distribution.
- (5) U-shaped 30,000 BTU burners—one per 12" of plate—for consistent edge-to-edge temperatures.
- Modulating thermostatic controls with standing pilots; 250 °F – 500 °F range for precision cooking.
- 24" deep cooking zone handles high-volume breakfast, lunch, and dinner items.
- 3" rear & side splash guard contains splatter; 3" stainless steel trough channels runoff to a large front grease pan.
- Stainless steel front, sides, and landing ledge resist corrosion and wipe clean quickly.
- 4" adjustable stainless steel legs stabilize the unit and simplify cleaning underneath.
- Field-convertible for Natural or Propane gas (3/4" NPT rear connection).
- ETL Listed for gas & sanitation compliance.
- Designed & built in California and backed by a 2-year parts & labor limited warranty.
Technical Specifications
| Model | ARTG-60-24 |
|---|---|
| Cooking surface | 60" W × 24" D (1524 × 610 mm) |
| Overall dimensions | 60" W × 35" D × 17" H (1524 × 889 × 432 mm) |
| Burners | 5 U-shaped, 30,000 BTU each |
| Total input | 150,000 BTU/hr (44 kW) |
| Temperature range | 250 °F – 500 °F (121 °C – 260 °C) |
| Gas connection | 3/4" NPT (rear) |
| Manifold pressure | Natural: 5.0" W.C. | LP: 10.0" W.C. |
| Plate thickness | 1" (25 mm) polished steel |
| Construction | Stainless steel front, sides, splash guard, grease trough & pan |
| Legs | 4" adjustable stainless steel |
| Shipping weight | Approx. 665 lb (302 kg) |
| Certifications | ETL (US & Canada), ETL Sanitation |
| Warranty | 2-year limited parts & labor |
Installation Notes
- Install on non-combustible floors only; legs or casters required, or provide ≥ 2" overhang when curb mounted.
- Clearances: 0" from non-combustible surfaces; 12" from combustible sides, 4" from combustible rear.
- Commercial ventilation hood required—follow NFPA 96 guidelines.
- Specify gas type and altitude (if over 2,000 ft / 610 m) when ordering.
Important: Shipping weight is approximate and includes packaging. Improper installation, unauthorized service, or use outside recommended conditions will void the warranty. Refer to the full installation & warranty documents for complete details.
Need a different size? The American Range ARTG series is also available in 24", 36", 48", and 72" widths.
Features & Specs
Features & Specs
Manufacturer
American Range
Certifications
ETL, Made in USA
Height
10.5in
Width
60.0in
Depth
30.0in
Shipping Weight
500.0lbs
Cooking Surface Width (side - side)
55" - 60"
Plate Thickness
3/4"
Griddle Plate Finish
smooth steel
Exterior Finish
stainless steel front & sides
Controls
thermostat / solid state controls
Specifications
Griddle, gas, 60" W x 24"D, countertop, 1" thick smooth polished steel griddle plate, (5) "U" shaped burners, modulating thermostatic controls with pilot, 3" splash guard, stainless steel grease trough & grease pan, stainless steel exterior, 4" legs, 44.0kW, 150,000 BTU, ETL, Made in USA
