American Range ARSTG-60 Thermostatic Countertop Griddle – 60"
150,000 BTU | Natural or LP Gas | Made in USAPower through the breakfast rush, lunch lines, and late-night service with the American Range ARSTG-60. This heavy-duty 60 inch griddle couples a mirror-smooth 1" steel plate with five independent modulating thermostats, giving chefs pinpoint control over 8.75 sq ft of cooking space. Built, tested, and certified in the USA, it is the reliable workhorse every high-volume kitchen needs.
Key Features
- 1" thick, highly polished steel griddle plate for superior heat retention and lightning-fast recovery.
- Expansive 60" W × 21" D cooking surface—handle multiple menu items at once.
- Five 30,000 BTU aluminized-steel “U” burners (one every 12") deliver a total of 150,000 BTU/hr.
- Modulating thermostats with standing pilots maintain 250 °F – 500 °F independent zones.
- Stainless steel front, 3 ¾" side splashes, and 4" rear splash keep grease and debris contained.
- 3" spatula-wide grease trough funnels into two large-capacity stainless steel drawers for quick clean-up.
- 4" adjustable stainless steel legs allow precise leveling and provide clearance for sanitation.
- ¾" rear NPT gas connection with regulator included; field convertible for Natural or LP gas.
- ETL listed for gas and sanitation—meets NSF/ANSI standards.
- Designed, engineered, and manufactured in the USA.
Specifications
| Model | ARSTG-60 |
|---|---|
| Gas Type | Natural or Liquid Propane (specify when ordering) |
| Total BTU Input | 150,000 BTU/hr |
| Burners | 5 × 30,000 BTU “U”-shaped |
| Cooking Surface | 60" W × 21" D, 1" thick polished steel |
| Thermostat Range | 250 °F – 500 °F |
| Overall Dimensions* | 60" W × 32 9/16" D × 18 7/16" H |
| Working Height* | 12 9/16" (with legs) |
| Shipping Weight | ≈ 643 lb |
| Gas Connection | ¾" rear NPT, 4.0" W.C. Nat / 10.0" W.C. LP |
| Exterior Construction | All stainless steel |
*Nominal dimensions; may vary ±1" with adjustable legs.
What’s Included
- (2) Stainless steel grease drawers
- ¾" gas pressure regulator
- Printed operator’s manual
Warranty
Two-year limited warranty on parts & labor, plus 90-day coverage on replacement parts. Register your griddle within 90 days of shipment for full protection.
