Key specifications

BTU
180,000 BTU
Dimensions
72.0"W × 29.5"D × 10.5"H
Type
Charbroiler
Installation Type
Countertop
Material
Stainless Steel
Country of Origin
USA
Spec sheet
American Range SKU: ARSRB-72

American Range ARSRB-72 72-Inch Gas 12-Burner Charbroiler

$5,842.86
/each
Estimated to ship in 11–14 business days Free Shipping
Width
Gas typeRequired
Gas Connector
Included: American Range warranty Two-year limited warranty for parts and labor

Get priority processing and free 1-year protection with PREMIUM Learn about Premium

As low as $540/mo with Credit Key Learn more

Questions before you buy?

Talk to a specialist — usually within 1 hour, 9am–6pm EST.

Questions before you buy?

Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.

Specifications

Type Charbroiler
Installation Type Countertop
Material Stainless Steel
Country of Origin USA
Width 72 Inches
Cooking Depth 21 Inches
Burner Count 12
BTU 180,000 BTU
Heating Source Radiant
Controls Manual
Grate Material Cast Iron
Grate Type Reversible
Leg Height 4 Inches
Radiants Removable
Grease Pan Full Width, Removable

Description

The American Range ARSRB-72 is a gas countertop charbroiler with 12 burners and 180,000 BTU output.

  • Heavy-duty reversible cast iron grates
  • 21-inch cooking depth
  • Manual controls with individual burner controls
  • Removable radiants and full-width grease pan
  • Stainless steel front and sides
  • Four-inch adjustable legs

Overall Dimensions:

72.0"W x 29.5"D x 10.5"H

Product Weight:

560.0 lb

12 Burners

The charbroiler has 12 burners with individual burner controls.

180,000 BTU Output

The unit is rated at 180,000 BTU.

Reversible Cast Iron Grates

Heavy-duty reversible cast iron grates are included.

Removable Radiants

The radiants are removable.

Full-Width Grease Pan

A full-width removable grease pan is included.

Manual Controls

The charbroiler uses manual controls.

Stainless Steel Construction

The front and sides are stainless steel.

Adjustable Legs

Four-inch adjustable legs are included.

Standing Pilot Ignition

The cutsheet specifies a standing pilot ignition system.

Frequently Asked Questions

It has 12 burners with individual burner controls.
The charbroiler includes heavy-duty reversible cast iron grates.
Yes. The ARSRB-72 is a gas countertop charbroiler.
The cutsheet provides natural gas and liquid propane selections and says the gas type must be specified when ordering. The supplied product record does not identify a selected gas type.
The product has a two-year limited warranty for parts and labor. Broiler burners, lower and upper grates, and radiants have a 90-day warranty duration.
The product is made in the USA.

This ships by freight truck on a pallet, not by a parcel carrier. The carrier calls ahead to set a delivery window, and an adult 18 or older must be there to receive, inspect and sign for it.

The driver brings it to the back of the truck, or lowers it to the ground with liftgate service. They don’t bring it inside, so plan for a pallet jack or two people to move it from the curb.
