American Range ARSMG-60 Gas Griddles
Description
American Range ARSMG-60 Manual Countertop Gas Griddle — 60" Wide
1" Polished Steel Plate | 5 U-Shaped Burners | 150,000 BTU | Made in USABuilt for high-volume breakfast, lunch, and dinner service, the American Range ARSMG-60 delivers rock-solid heat retention and even searing across a generous 60" x 21" cooking surface. Five independently-controlled 30,000 BTU burners let you run multiple temperature zones, while the extra-thick polished plate locks in heat for a perfect finish from pancakes to proteins.
Key Features
- 1" thick smooth polished steel griddle plate holds temperature and resists warping
- Five U-shaped aluminized steel burners (30,000 BTU each) for a total of 150,000 BTU
- Manual brass gas valves for infinite heat adjustment from 250 °F – 500 °F
- 60" wide x 21" deep cooking area — approx. 1,260 in² of usable surface
- Stainless steel front, sides, 3 3/4" side splashes, and 4" rear splash help contain grease & debris
- 3" spatula-wide trough feeds into two large-capacity stainless steel grease drawers
- 4" adjustable stainless steel legs for easy leveling on any countertop
- 3/4" rear gas connection with regulator — field convertible to Natural or LP gas
- ETL Listed for gas & sanitation; designed and built in the USA
- Two-year limited parts & labor warranty
Specifications
| Model | ARSMG-60 |
|---|---|
| Plate Thickness | 1" (25 mm) smooth polished steel |
| Cooking Surface | 60" W × 21" D |
| Overall Dimensions | 60" W × 32 9/16" D × 18 7/16" H |
| Working Height | 12 9/16" (with legs adjusted to minimum) |
| Burners / BTU | 5 U-shaped burners | 150,000 BTU total |
| Controls | Manual gas valves (infinite) |
| Gas Inlet | 3/4" NPT rear connection (pressure regulator included) |
| Weight | Approx. 643 lb (shipping) |
| Certifications | ETL (US & Canada) Gas & Sanitation |
| Origin | Pacoima, CA | North Las Vegas, NV – USA |
Why Choose American Range
- Heavy-duty construction built to thrive in demanding commercial kitchens
- Rapid lead times and parts availability from a U.S.-based manufacturer
- Backed by a comprehensive two-year limited warranty and nationwide service network
Note: This appliance is intended for commercial installation only. Clearances of 6" (152 mm) are required at both sides and rear when installed next to combustible materials. Please specify gas type and altitude (if above 2,000 ft) when ordering.
