American Range ARGF-24G-6B-126L Gas Ranges
Description
Green Flame 60" Gas Range with 24" Griddle & 6 Open Burners
American Range Model ARGF-24G-6B – Standard & Space-Saver OvensBuilt for the busiest commercial kitchens, the American Range Green Flame series delivers high-efficiency, pilotless performance in a single, hard-working footprint. With six high-output burners, a full-size griddle and two independent ovens, this 60" range gives your team the flexibility to sear, sauté, grill and bake—all at once.
Key Benefits
- Six 25,000 BTU open burners under heavy-duty 12" × 12" cast-iron grates.
- 24" manual griddle with a 1" thick steel plate; dual 20,000 BTU burners provide even heat.
- Pilotless electronic ignition on every top burner, griddle and oven—cuts energy costs and keeps kitchens cooler.
- Left 26-1/2" standard oven (35,000 BTU) + right 20" space-saver oven (27,000 BTU); each ships with two chrome racks.
- Precise 250 – 500 °F thermostat range; porcelain-enameled interiors wipe clean fast.
- Stainless steel front, sides and 6" deep landing ledge stand up to daily abuse.
- Choose your backguard at no charge: 6" stub back, 20" riser, or full high-shelf riser.
- 6" adjustable chrome-plated legs; optional casters available.
- cETLus & ETL-Sanitation listed; proudly Made in the USA.
- Protected by a 2-year parts & labor warranty from American Range.
Performance & Specs
| Total Input | 282,000 BTU/h • 83.0 kW |
|---|---|
| Open Burners | 6 × 25,000 BTU |
| Griddle | 24" W × 1" thick plate, 2 × 20,000 BTU tube burners |
| Left Oven | 26-1/2" standard, 35,000 BTU • 250-500 °F |
| Right Oven | 20" space-saver, 27,000 BTU • 250-500 °F |
| Oven Racks | 2 chrome racks per oven (4 total) |
| Exterior Size (W × D) | 60" × 32-1/2" (1524 × 826 mm) |
| Cooking Surface Height | Approx. 36" (914 mm) |
| Gas Connection | 3/4" NPT rear; Natural or LP (specify) |
| Electrical | None required |
| Net Weight | ≈ 757 lb (343 kg) |
Shipping weight includes packaging. Install on non-combustible floors and follow local code & NFPA 96 ventilation requirements.
What’s in the Box
- Range with selected backguard
- Four chrome oven racks
- Full-width removable drip tray & 3" grease drawer
- Installation and operation manual
Certifications
- cETLus – complies with ANSI Z83.11 / CSA 1.8
- ETL-Sanitation – NSF/ANSI 4
