American Range AR-8-CL-SBR Gas Ranges
Description
American Range AR-8-CL-SBR 48" Gas Restaurant Range
8 Open Burners • Left-Side 26 ½" Convection Oven • Right-Side Storage BaseBuilt for high-output commercial kitchens, the Made-in-USA AR-8-CL-SBR combines searing, simmering and baking power in one 48" footprint. Eight 32,000 BTU open burners sit above a full 26 ½" convection oven, while an 11" integrated storage base keeps sheet pans and utensils close at hand.
Why you’ll love it
- Massive 286,000 BTU total output (84 kW) for non-stop rush periods
- Convection oven fan delivers even heat for faster, consistent bakes & roasts
- Heavy-duty 12" × 12" cast-iron grates lift off for quick cleaning
- Porcelain-enamel oven interior wipes clean in seconds
- All-stainless front & sides with 6" landing ledge stand up to daily abuse
- Choice of 6" stub back, 20" riser, or high riser with shelf included
- Two-year parts & labor warranty backed by American Range’s nationwide service network
Performance & capacities
| Open burners | 8 × 32,000 BTU lift-off (256,000 BTU) |
|---|---|
| Convection oven burner | 30,000 BTU |
| Total input | 286,000 BTU / hr • 84.0 kW |
| Oven interior (W × D × H) | 26 ½" × 22 ½" × 13 ½" |
| Oven racks | 2 chrome racks, 5 positions |
| Storage base width | 11" (inside) |
| Thermostat range | 250 °F – 500 °F (121 °C – 260 °C) |
Construction highlights
- Stainless steel front, sides, backguard & landing ledge
- 6" chrome-plated adjustable legs (option: locking casters)
- Removable full-width drip pan under burners
- Spring-assisted, counter-weighted oven door
- Cool-touch, high-temperature burner knobs
Utilities & connections
| Gas type | Natural or LP (specify when ordering) |
|---|---|
| Manifold pressure | 5.0" W.C. Natural • 10.0" W.C. LP |
| Gas connection | ¾" NPT rear |
| Electrical (convection fan) | 120 V / 1-Phase / 1 Amp, 15 A cord & plug included |
| Shipping weight | Approx. 570 lb (259 kg) |
| Certifications | cETLus • ETL-Sanitation (NSF-equivalent) |
Popular options
- Set of 4 swivel casters (front two locking)
- High riser with integrated shelf
- Additional chrome oven racks
Install on non-combustible floors with adequate ventilation per NFPA 96. 12" side and 4" rear clearances required from combustible walls.
