72" Gas Restaurant Range with Full-Width Griddle, Standard Oven & Storage Base
American Range • Model AR-72G-DSB (Manual Griddle)Built for busy diners, hotels, and high-volume restaurants, this USA-made American Range unit delivers a massive 72" cooking surface, a powerful 35,000 BTU oven, and a convenient storage cabinet—all in one rugged footprint.
Key Features
- Full-width 72" griddle with 1" thick cold-rolled steel plate for superior heat retention.
- Six 20,000 BTU cast-iron burners (one every 12")—each with independent manual control for multi-zone cooking.
- 3" grease trough and large-capacity removable drawer for fast clean-up.
- Left-side 26 ½" standard oven (35,000 BTU) with 250 °F–500 °F thermostat and 100 % safety shut-off.
- Porcelain-enamel oven interior plus two chrome racks with four position guides.
- Right-side 26 ½" storage base keeps sheet pans, utensils, or dry goods within reach.
- Stainless steel front, sides, backsplash and 6" deep landing ledge resist dents and corrosion.
- 6" adjustable chrome-plated legs for easy leveling on uneven floors.
- Choose your backguard at no extra charge: 6" stub back, 20" riser, or 20" riser with shelf.
- Total input: 155,000 BTU (46.0 kW). Factory-set for Natural or LP gas (specify on order).
- cETLus & ETL-Sanitation listed; proudly Made in the USA.
Ideal For
Breakfast houses, burger concepts, cafeterias, hotels—any operation that relies on a large, consistent griddle but still needs baking, roasting, or warming capacity without giving up valuable line space.
Specifications
| Cooktop | 72" manual griddle, 1" thick, 6 × 20,000 BTU burners |
|---|---|
| Oven (Left) | Standard oven, 26 ½" W × 22 ½" D × 13 ½" H interior; 35,000 BTU |
| Storage (Right) | 26 ½" enclosed cabinet with hinged door |
| Total BTU | 155,000 BTU (46.0 kW) |
| Gas Connection | 3/4" NPT rear; 5.0" W.C. Natural or 10.0" W.C. LP |
| Overall Dimensions | 72" W × 32 ½" D × 56" H (with 20" riser) |
| Clearances* | 0" rear & sides to non-combustible; 6" to combustible |
| Certifications | cETLus, ETL-Sanitation |
| Origin | Designed & built in the United States |
What’s Included
- (2) chrome-plated oven racks
- Removable grease drawer
- 6" adjustable legs
- Your choice of backguard (stub, riser, or riser with shelf)
Popular Options & Accessories
- Swivel casters (set of 6, three with brakes)
- Thermostatic griddle controls
- Convection oven or additional storage base in lieu of standard oven (factory-built)
- Extra oven racks
Important: This appliance must be installed under a ventilation hood
in accordance with NFPA-96 or local codes. Gas type, altitude, and backguard choice must
be specified at the time of order. Professional installation and start-up are required
to maintain warranty coverage.
Backed by American Range’s two-year parts & labor warranty and 90-day griddle component warranty. Refer to the full warranty statement for complete details.
$11,932.47
/each
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Restaurant Range, gas, 72", (1) 72" griddle, 1" thick plate, manual controls, (1) 26 1/2" standard oven on left, (2) racks, (1) 26 1/2" storage base on right,stainless steel front, sides, choice of high shelf and riser, 20" riser or 6" stub back, 6" adjustable chrome plated legs, 46.0kW, 155,000 BTU, cETLus, ETL-Sanitation, Made in USA
Manufacturer
American Range
Certifications
cETLus, ETL-Sanitation, Made in USA
Height
36.0in
Width
72.0in
Depth
32.5in
Shipping Weight
815.0lbs
Exterior Finish
all stainless steel exterior
Plate Thickness
1.000" = 1"
Top
(1) griddle
Base
(1) standard oven, (1) cabinet
Specifications
Restaurant Range, gas, 72", (1) 72" griddle, 1" thick plate, manual controls, (1) 26 1/2" standard oven on left, (2) racks, (1) 26 1/2" storage base on right,stainless steel front, sides, choice of high shelf and riser, 20" riser or 6" stub back, 6" adjustable chrome plated legs, 46.0kW, 155,000 BTU, cETLus, ETL-Sanitation, Made in USA
