American Range 60" Gas Restaurant Range with 48" Manual Griddle & 2 Burners
Model reference: AR-48G-2B (Convection Left / Standard Right)Engineered and built in the USA for the high-volume commercial kitchen, this 60" American Range gives you a full 48" of 1"-thick griddle cooking surface, two powerful open burners, and a split oven base with a convection oven on the left and a standard oven on the right. A combined 209,000 BTU of fire power, heavy-gauge stainless construction, and cETLus & ETL-Sanitation certifications make it a true workhorse that’s ready for the rush.
Highlights
- 60" wide commercial range, 32 ½" deep cooking surface, 36" working height
- 48" manual griddle on the left — 1" thick steel plate with 3" grease trough
- (2) 32,000 BTU open burners with 12" x 12" cast-iron grates
- Split oven base: 26 ½" convection oven (left) & 26 ½" standard oven (right)
- Total input 209,000 BTU | 61.0 kW
- Stainless steel front, sides, landing ledge & kick plate; welded frame construction
- Choice of back: 6" stub, 20" riser, or high shelf with riser (select when ordering)
- 6" adjustable chrome-plated legs
- Made in the USA — cETLus and ETL-Sanitation listed
Performance at a Glance
- Griddle burners: 20,000 BTU each × 4 sections (80,000 BTU)
- Open top burners: 32,000 BTU each × 2 (64,000 BTU)
- Convection oven burner: 30,000 BTU / Fan motor 120 V, 1 Φ, 4 A
- Standard oven burner: 35,000 BTU
- Oven thermostat range: 250 °F – 500 °F (121 °C – 260 °C)
Technical Specifications
| Overall width | 60" (1524 mm) |
|---|---|
| Overall depth | 32 ½" (826 mm) |
| Cooking height | 36" (914 mm) on 6" adjustable legs |
| Griddle plate | 48" W × 24" D, 1" thick cold-rolled steel |
| Open burners | (2) 12" x 12" lift-off cast-iron grates, 32,000 BTU each |
| Oven cavity (each) | 26 ½" W × 22 ½" D × 13 ½" H |
| Racks supplied | (2) chrome racks per oven, removable guides (5 positions convection / 3 positions standard) |
| Total input | 209,000 BTU | 61.0 kW |
| Gas connection | 3/4" NPT rear manifold Natural 5.0" W.C. / LP 10.0" W.C. |
| Electrical (fan) | 120 V, 1-phase, 4 A | 15 A plug included |
| Certifications | cETLus, ETL-Sanitation |
| Origin | Designed & built in the USA |
What’s in the Box
- American Range 60" griddle/burner range (base unit)
- (4) griddle burners & manual control valves
- (2) open top burners with lift-off grates & drip pans
- (4) chrome oven racks (2 per oven)
- 6" adjustable chrome legs (installed)
- Removable grease drawer & crumb tray
- User & installation manual
Certifications & Warranty
- cETLus & ETL-Sanitation listed for gas safety and NSF sanitation
- 2-year limited parts & labor warranty (90 days for replacement parts)
- Extended coverage available with timely product registration (details)
Perfect For
- High-volume diners, cafes, and breakfast houses
- Steak & burger programs requiring simultaneous griddle and sauté production
- Catering or banquet kitchens needing split oven versatility
- Food-truck commissaries and ghost kitchens that demand robust, compact equipment
Important: Specify gas type (Natural or Propane) and back configuration (stub back, 20" riser, or high shelf) when ordering. Installation must comply with all local codes and ventilation requirements.
Photos may show equipment with optional accessories. Specifications are subject to change without notice.
$12,876.30
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
American Range 60" gas restaurant range with 48" griddle, dual ovens, 32,000 BTU burners, stainless steel, heavy-duty, cETLus certified, Made in USA
Manufacturer
American Range
Certifications
cETLus, ETL-Sanitation, Made in USA
Height
56.0in
Width
60.0in
Depth
32.25in
Shipping Weight
805.0lbs
Base
(1) standard oven, (1) convection oven
Control Type
manual controls
Plate Thickness
1.000" = 1"
Top
(2) open burners, (1) 48" griddle
Exterior Finish
stainless steel front & sides
Specifications
Restaurant Range, gas, 60", (1) 48" griddle on left, 1" thick plate, manual controls, (2) 32,000 BTU open burners, (1) 26-1/2" convection oven on left, (1) 26-1/2" standard oven on right, (2) racks each oven, stainless steel front, sides, choice of high shelf and riser, 20" riser or 6" stub back, 6" adjustable chrome plated legs, 61.0kW, 209,000 BTU, cETLus, ETL-Sanitation, Made in USA
