American Range | SKU:
AR-4-SB
American Range AR-4-SB Gas Ranges
$2,782.55
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
American Range AR-4-SB Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
American Range AR-4-SB Gas Ranges
$2,782.55
Unit price
/
Unavailable
Description
American Range 24" Gas Restaurant Range with Storage Base – 4 Open Burners
Model AR-4-SB | 100,000 BTUBuilt for demanding commercial kitchens that need power in a tight footprint, the American Range AR-4-SB packs four high-performance open burners and a convenient 20" storage base into a rugged 24" frame—all proudly made in the USA.
Key Features
- (4) lift-off cast-iron open burners—each rated up to 32,000 BTU—for quick boils, steady sautés, and low-simmer finesse.
- Space-saving 20" storage cabinet keeps sheet pans, stock pots, or cleaning supplies right where you need them.
- Stainless steel front, sides, landing ledge, and removable full-width drip pan stand up to daily abuse and wipe clean fast.
- Choose your backsplash at no extra cost: 6" stub back, 20" riser, or 20" riser with integrated high shelf.
- 6" chrome-plated adjustable legs level the range on uneven floors and provide a comfortable 36" cooking height.
- Field-convertible for Natural or Propane gas (specify when ordering).
- Certified cETLus & ETL-Sanitation for compliance with NSF/ANSI standards.
- Backed by a true 2-year parts & labor limited warranty.
- Designed & built in the USA for lasting performance and easier parts availability.
At-a-Glance Specs
| Overall width | 24" (610 mm) |
|---|---|
| Overall depth | 32 1/2" (826 mm) |
| Cooking height | 36" (914 mm) on 6" legs |
| Total input | 100,000 BTU / 29.0 kW |
| Burners | 4 × 32,000 BTU open burners |
| Base | 20" space-saver storage cabinet |
| Gas connection | 3/4" NPT (rear) |
| Manifold pressure | Natural 5.0" W.C. | Propane 10.0" W.C. |
| Certifications | cETLus, ETL-Sanitation |
| Warranty | 2-year parts & labor (90-day replacement parts) |
| Shipping weight | Approx. 245 lb (111 kg) |
What’s Included
- Backsplash style of your choice (stub back, 20" riser, or 20" riser with high shelf)
- (4) 12" × 12" heavy-duty cast-iron top grates
- Full-width removable drip/crumb pan
- Installation & operation manual
Gas & ventilation notice: This appliance must be installed by a qualified technician in accordance with all local codes. A compliant exhaust hood and adequate make-up air are required.
Need help configuring your cookline or selecting accessories? Chat with our equipment pros—we’re here to help.
Features & Specs
Features & Specs
Manufacturer
American Range
Certifications
cETLus, ETL-Sanitation, Made in USA
Height
36.0in
Width
24.0in
Depth
32.5in
Shipping Weight
260.0lbs
Exterior Finish
stainless steel front & sides
Top
(4) open burners
Vent
backriser with hi-shelf
Base
(1) cabinet
Specifications
Restaurant Range, gas, 24", (4) 32,000 BTU open burners, (1) 20" space saver storage base, stainless steel front, sides, choice of high shelf and riser, 20" riser or 6" stub back, 6" adjustable chrome plated legs, 29.0kW, 100,000 BTU, cETLus, ETL-Sanitation, Made in USA
