Description

American Range AR-12G-2B-SB 24" Gas Restaurant Range

12" manual griddle • 2 open burners • storage base • 84,000 BTU

Pack more versatility into just 24 inches of cookline real-estate. Built and certified for the rigors of commercial service, the AR-12G-2B-SB combines a full-thickness steel griddle, two powerful open burners, and a spacious 20" storage cabinet—all wrapped in heavy-gauge stainless steel and proudly Made in the USA.

Why this range rocks

84,000 BTU total output – rapid recovery even at peak rush.
12" x 24" manual griddle with a 1" thick plate for superior heat retention.
Two 32,000 BTU open burners with lift-off heads & 12" x 12" cast-iron grates.
20" storage base replaces the oven—perfect for sheet pans, stock pots & supplies.
6" deep front landing ledge doubles as a plating / staging surface.
Choose your backsplash: 6" stub, 20" riser, or 20" riser with high shelf (no up-charge).
Removable full-width crumb/drip pan and 3" grease trough for easy clean-ups.
6" adjustable chrome-plated legs level the unit on uneven floors.
cETLus & ETL-Sanitation listed; backed by a 2-year parts & labor warranty.

Engineered for performance

Open burners: 32,000 BTU/hr each, anti-clog lift-off heads, removable cast-iron grates.
Griddle section: one 20,000 BTU burner every 12"; manual gas valve control.
Heat distribution: 1" steel plate and extra-wide grease collector reduce flare-ups and deliver even searing from corner to corner.

Construction highlights

Stainless steel front, sides, back, and landing ledge.
Robust welded frame supports heavy cookware without flex.
All controls are front-mounted, keeping hands safely away from the cooking surface.
Access panel at rear simplifies gas line installation and servicing.

Specs at a glance

Model	AR-12G-2B-SB
Gas type	Natural or Propane (field convertible)
Total BTU	84,000 BTU / 25.0 kW
Open burners	2 × 32,000 BTU
Griddle plate	12" W × 24" D × 1" thick (305 mm)
Storage base	20" W cabinet (no oven)
External dimensions	24" W × 32 1/2" D × 56" H * (610 × 826 × 1,422 mm)
Cooking height	36" (914 mm) to cooktop
Gas connection	3/4" NPT rear manifold Nat 5.0" W.C. \| LP 10.0" W.C.
Shipping weight	Approx. 260 lb (118 kg)
Certifications	cETLus, ETL-Sanitation, Made in USA
Warranty	2 years parts & labor (see warranty terms)

*Height shown with 20" riser. Overall height varies with backsplash selection.

Popular options (sold separately)

Swivel casters (set of 4, two locking)
20" riser with single or double high shelf
6" stainless stub back (low profile install)
Thermostatic griddle control package
LP conversion kit

Installation notice: Unit must be installed by a qualified technician in accordance with local codes. Maintain 0" clearance to non-combustible surfaces, or 12" sides / 4" rear to combustibles. Gas supply, venting, and start-up calibration are not included.

Features & Specs

Manufacturer

American Range

Height

56.0in

Width

24.0in

Depth

32.25in

Shipping Weight

260.0lbs

Base

(1) cabinet

Exterior Finish

stainless steel front & sides

Top

(2) open burners, (1) 12" griddle

Plate Thickness

1.000" = 1"

Specifications

Restaurant Range, gas, 24", (1) 12" griddle on left, 1" thick plate, manual controls, (2) 32,000 BTU open burners, (1) 20" storage base, stainless steel front, sides, choice of high shelf and riser, 20" riser or 6" stub back, 6" adjustable chrome plated legs, 25.0kW, 84,000 BTU, cETLus, ETL-Sanitation, Made in USA
