Advance Tabco DISLRCP-3 Slimline Drop-In Refrigerated Cold Well
3-Pan Self-Contained Unit | 115 V Plug-and-PlayTurn any existing countertop into a high-performance cold station. The DISLRCP-3 keeps salads, bottled drinks, toppings and grab-n-go items safely chilled in a compact 71 ¼ inch footprint—perfect for cafés, cafeterias and catered events where every inch counts.
Why You’ll Love It
- Three fully refrigerated 12 × 20 inch wells accept pans up to 6 ¼ in. deep with extra space below for cold-air circulation.
- 18 ga. #304 stainless steel top with black polyethylene thermal-breaker marine edge—comfortable to lean on and helps block heat transfer.
- Foamed-in-place insulation (1 ¼ in. walls / 2 in. bottom) drastically reduces heat gain for lower energy use.
- Aluminum-encased copper tube evaporator panels maximise surface contact for rapid, even cooling.
- Digital, programmable thermostat delivers precise 33–41 °F holding temperatures.
- Self-contained R404A refrigeration system with hermetically sealed 1/5 HP compressor—no remote lines to run.
- Expansion valve, filter drier, sight glass and liquid receiver improve efficiency and simplify service.
- One-piece 18 ga. #304 stainless liner with 3 in. recessed top, coved ¼ in. corners and 1 in. I.P.S. drain for fast clean-ups.
- Adapter bars & rails included so you can mix-and-match standard hotel pans right out of the box.
- Ships with an 8 ft. cord & NEMA 5-15P plug—just drop in, plug in and chill.
- ETLus & ETL-Sanitation listed for electrical safety and food-contact compliance.
Technical Specifications
| Model | DISLRCP-3 |
|---|---|
| Number of Wells | 3 (12 × 20 in.) |
| Overall Dimensions | 71 ¼ W × 18 ⅝ D × 24 ⅛ H in. |
| Countertop Cut-Out | 70 W × 17 ⅜ D in. |
| Pan Depth Capacity | Up to 6 ¼ in. |
| Compressor | 1/5 HP, hermetically sealed |
| Refrigerant | R404A (environmentally friendly) |
| Temperature Range | 33 – 41 °F (0.5 – 5 °C) adjustable |
| Electrical | 115 V / 60 Hz / 8 A | NEMA 5-15P plug |
| Drain | 1 in. I.P.S. threaded |
| Unit Weight | 257 lb |
| Certifications | ETLus, ETL-Sanitation |
Installation & Operation Notes
- Provide a minimum of 200 in² unobstructed intake and 200 in² exhaust ventilation in enclosed cabinets to maintain warranty coverage.
- Designed to hold pre-chilled food only; product should enter the well at safe serving temperatures.
- Adapter bars supplied: (2) left-to-right rails & (4) front-to-back supports (kit SU-P-513).
California Proposition 65 Warning: This product can expose you to chemicals including Ethanes, known to the State of California to cause cancer and birth defects or other reproductive harm.
For more information visit the
Prop 65 website.
Advance Tabco continually improves products; specifications are subject to change without notice.
$4,840.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Advance Tabco slim 3-well refrigerated drop-in unit: digital thermostat, stainless steel, R290 self-contained cooling, ETL-Sanitation certified.
Manufacturer
Advance Tabco
Certifications
ETLus, ETL-Sanitation
Height
24.13in
Width
71.25in
Depth
18.63in
Shipping Weight
257.0lbs
Layout
narrow
Insulation
insulated
Finish
stainless steel top & inner liner, galvanized outer liner
Style
self-contained refrigeration
Pan Size
full-size (12" x 20")
Width (side - side)
67 - 72 inches
Pan Qty
3-pan
Specifications
Slim Series Cold Food Well Unit, drop-in, (3) refrigerated wells (accommodates pan inserts up to 6-1/4" deep, with additional space below for cold air circulation), 71-1/4"W x 18-5/8"D x 24-1/8"H (overall), 70"W x 17-3/8"D (cut out size), digital programmable thermostat, stainless steel top with extruded black polyethylene thermal breaker marine edge, stainless steel inner lining with 3" recessed top, galvanized steel outer lining, self-contained refrigeration, R290 refrigerant, 1" I.P.S. drain, ETLus, ETL-Sanitation
