AccuTemp ALTLGB-60 Edge Series™ Steam Kettles
Description
AccuTemp Edge Series™ 60-Gallon Gas Tilting Kettle
Model ALTLGB-60 | Self-Contained | 2/3 Jacketed | 30 PSIProduce soups, sauces, pastas and stocks at scale—all with the speed, precision and safety professional kitchens demand. The Edge Series™ 60-Gallon Gas Tilting Kettle brings 108,500 BTU of even, steam-jacketed power together with AccuTemp’s rugged deep-drawn stainless construction for a dependable, operator-friendly workhorse.
Why Kitchens Choose Edge Series
- 60 gal (227 L) working capacity handles high-volume production with ease
- Self-contained 2/3 steam jacket—no external boiler or steam hookup required
- 108,500 BTU (LP) / 106,800 BTU (Natural) burners for rapid heat-up
- 304 SS deep-drawn liner & jacket—seamless, stick-resistant & easy to clean
- Full-body Insulated for Safety™ design keeps exterior cool & saves energy
- Thermostat control 150 °F–260 °F (65 °C–126 °C) with dependable electronic ignition
- Kettle Protection System with automatic low-water shut-off safeguards the jacket
- Self-locking, permanently lubricated worm-gear tilt for smooth, one-person pouring
- 2" tubular stainless frame & adjustable flanged feet ensure rock-solid stability
- UL Gas-Fired & NSF listed; proudly engineered and built in the USA
Built-In Safety & Convenience
- Pressure relief valve, air eliminator & pressure gauge for worry-free operation
- Water fill valve with sight glass for quick visual checks
- Tilting cut-off switch automatically shuts burners off when kettle is raised
- Seam-welded stainless control console resists splashes and corrosion
- Runs on just 120 V, 1 ph, 1 A—no standing pilot to relight
Technical Specifications
| Capacity | 60 gal / 227 L |
|---|---|
| Heating Source | Natural or Propane Gas |
| Input | Natural: 106,800 BTU /h | Propane: 108,500 BTU /h |
| Gas Connection | 3/4" IPS (rear) |
| Jacket Rating | 30 PSI (207 kPa) |
| Thermostat Range | 150 °F–260 °F (65 °C–126 °C) |
| Electrical | 120 V, 50/60 Hz, 1 ph, 1 A (electronic ignition) |
| Construction | 304 SS liner & jacket, seam-welded |
| Frame | 304 SS, 2" tubular, floor-mounted with flanged feet |
| Tilt Mechanism | Self-locking worm gear, permanently lubricated |
| Certifications | UL Gas-Fired, NSF |
| Warranty | 1 Year parts & labor |
Popular Accessories (sold separately)
- 2" or 3" draw-off valve (compression or ball type)
- Lift-off cover or actuator-assisted hinged lid
- 60" flexible gas hose & quick-disconnect kit
- Disc strainers, single or tri-basket inserts & nylon bag system
- Electric timer with buzzer for precise batch control
- Automatic water fill meter & measuring strip
- Care & maintenance kit
Looking for CAD drawings, installation guidance or custom configurations? Reach us anytime at service@accutemp.net—our food-service specialists are happy to help.
